From Handcrafted to High-Tech: The New Trend of Neon Signs
The glowing script of a classic marquee and the vibrant lines of a modern facade both achieve the same striking visual effect, but through fundamentally different technologies. The craft of bending glass tubes by hand is being preserved and taught globally, while flexible, low-voltage LED systems have created an expansive new toolkit for designers. This guide connects these two threads, explaining the physics, the artisan process, the critical compliance codes, and the modern controls that define today’s illuminated signage landscape.
What Are the Main Types of Neon Signs?
What is commonly called “neon” encompasses two distinct systems that produce a continuous linear light effect.
1. Traditional Cold-Cathode Discharge (Glass Neon)
Traditional installations rely on hand-formed glass tubes filled with rare gases at low pressure.
- Neon Gas: Produces the characteristic red-orange glow.
- Argon/Mercury: Argon gas combined with a small amount of mercury vapor produces a bluish discharge light. This light is used to excite an internal phosphor coating on the glass, enabling the creation of a wide spectrum of colors.
- How it Works: The finished lamp is a cold-cathode discharge device driven by high-voltage (several kilovolts) at controlled current. This physics necessitates strict safety rules.
2. Modern Solid-State Lighting (LED Neon Flex)
The modern counterpart, often termed “LED neon” or “LED neon flex,” uses a continuous row of solid-state LEDs housed within a flexible, diffused silicone or PVC jacket.
- How it Works: These low-voltage runs typically operate on 12–24 volts DC, powered by Class 2 power supplies.
- Advantage: The entire system operates at safer voltage and current levels, contributing to touch-safe characteristics and simpler wiring methods compared to high-voltage glass.
What’s the Difference Between Glass and LED Neon Signs?
| Aspect | Traditional Glass Neon | Modern LED Neon Flex |
| Construction | Hand-formed over heat, evacuated, bombarded (cleaned/heated), filled with gas, and sealed. Electrodes are welded on. | LEDs assembled on a flexible circuit board, encased in an extruded, diffused jacket. |
| Physics | High-voltage cold-cathode discharge. | Low-voltage solid-state illumination. |
| Voltage | Kilovolts (kV) | 12–24 Volts (V) |
| Visual Texture | Unmistakable deep glow and the visual texture of real glass. | High visual uniformity, excellent mimicry of the glow. |
| Cultural Value | Recognized for historic authenticity and preservation (e.g., U.S. National Park Service guidance, The Neon Museum). | Favored for dynamic effects and ease of deployment. |
What Codes Govern Neon LED Sign Safety?
Compliance is non-negotiable for all illuminated signage projects. Naming these references in a proposal or submittal demonstrates technical competence. For businesses selecting certified systems, Miami Custom Neon signs emphasizes UL-listed components and NEC-compliant installations, ensuring every project meets U.S. safety and performance standards.
Installation Code (U.S.)
- NEC Article 600 (NFPA 70): The foundational installation code for all electric signs and outline lighting in the U.S. Authorities Having Jurisdiction (AHJs) use this as the baseline for all approvals.
Safety and Product Listings (UL Standards)
| Standard | Technology Covered | Purpose |
| UL 48 | Both Glass and LED | Covers the safety of electric signs at the product level. |
| UL 879 | LED Components | Addresses safety of general electric sign components. |
| UL 879A | LED Retrofits | Applies to LED sign kits and retrofits. Note a current revision is aligned to an effective date in October 2025. |
| UL 2161 | Traditional Glass | Governs high-voltage neon transformers and power supplies and requires Secondary Ground-Fault Protection (SGFP) to reduce fire and shock hazards. |
| UL 1310 (Class 2) | Flexible LED | Specifies the safety criteria for Class 2 power units that limit output, enabling simpler wiring methods for low-voltage LEDs. |
Energy and Environmental Rules
- Energy Codes: Codes like California’s Title 24, Part 6 explicitly require neon sign lighting controls such as automatic shutoff, astronomical or time-switch scheduling, and nighttime power reduction. This logic is increasingly adopted in national standards.
- End-of-Life Handling:
- U.S. EPA: Spent argon/mercury-containing glass tubes fall under the “universal waste” framework, promoting recycling over disposal.
- European Union (EU): The RoHS directive limits mercury and other hazardous substances in electrical equipment.
The Control and Efficiency Behind Modern LED Neon
Powerful control capabilities often drive the shift to flexible solid-state systems.
- Dynamic Color and Motion: LED systems using RGB or RGBW strips can be controlled via DMX512-A (the standard entertainment-lighting protocol). This enables smooth fades, chases, complex synchronized effects, and dynamic scene changes for branding or hospitality.
- App and Cloud Control: Modern platforms allow for remote scene creation, scheduling, remote updates, and easy integration with energy-saving requirements, reducing operational friction.
- Exterior Durability: For outdoor use, the critical specification is the Ingress Protection (IP) rating (e.g., IP65, IP66, IP67, or IP68), which must be confirmed on the technical datasheet to guarantee resistance to dust and moisture.
Selecting the Best Neon Signage for Your Project
The best technology depends entirely on the design goals and constraints of the project.
| Project Goal | Recommended Approach & Specifications |
| Authenticity & Restoration | Traditional Glass Neon. Reference NEC Article 600. Specify UL 48 for the system and UL 2161 for power supplies with SGFP. Budget for skilled glass benders and include an EPA universal-waste recycling plan for mercury-bearing tubes. |
| Flexibility & Dynamics | Flexible LED Neon. Reference NEC Article 600. Specify UL 48 and UL 879 components. Use UL 879A kits for retrofits. Power the runs with UL 1310 Class 2 drivers at 12–24 V. Verify IP ratings and adopt DMX512-A controls from the outset if motion or color changes are required. |
Summary
The future of illuminated signage is no longer about choosing between nostalgia and innovation; it’s about integration. Traditional glasswork continues to embody artistry and heritage, while advanced LED systems represent adaptability, sustainability, and intelligent control. Together, they define a new era of visual communication where design meets data and creativity meets compliance. Whether it’s a handcrafted marquee or a programmable facade, the enduring appeal lies in light that tells a story, and that story keeps evolving.
